SounDigital 5000.1 XP Amplifier
1-Channel High-Power Amplifier in 1Ω Version
Description
Old school power. Modern control. No fluff.
The XP 5000.1 is SounDigital’s latest release in the “next-gen” XP line—but let’s cut through the hype. Under the hood, this amplifier carries the same muscle as its EVOX2 brother, just tuned with some extra polish. You’re still getting that unmistakable SounDigital punch—5,000W RMS in a compact footprint that’ll fit damn near anywhere—but now with a smarter layout, tighter filters, and an optional remote for quick level control.
Built to run hard and stay clean, the XP 5000.1 is all about delivering loud, tight, and reliable bass. It’s 1-ohm or 2-ohm stable, high-efficiency, and packed with all the proper crossovers, bass boost, subsonic filtering, and protection circuits you’d expect from a serious SPL-minded amplifier. You get rock-solid signal integrity, high SNR, and build quality that holds its own against the heaviest hitters in the game.
Whether you're running a comp-grade build or just want clean, relentless power to your substage, the XP 5000.1 does the job without compromise. It's not reinventing the wheel—just refining it.
Specifications / Information:
1 Ohm Version
Power Output (RMS)
@ 4Ω: 1 x 2250W
@ 2Ω: 1 x 3350W
@ 1Ω: 1 x 5000W
Operating Voltage: 9V – 16V
Input Sensitivity (RCA): 0.2V – 2V
Input Sensitivity (High Level): 1.5V – 15V
Signal-to-Noise Ratio (SNR): 99dB
Frequency Response (-3dB): 5Hz – 6kHz
Subsonic Filter: 5Hz – 40Hz
Low Pass Filter: 50Hz – 6kHz
Bass Boost: 0 – 12dB @ 50Hz
THD + N (at 10% rated power): Not explicitly stated, but assumed <1% based on lab calibration info
Damping Factor: >1000
Current Draw (Music): 195A
Current Draw (Max): 390A
Recommended Fuse: 200A
Recommended Battery Capacity: 200Ah
Power Cable: 70mm² (000 AWG)
Speaker Cable: 2 x 16mm² (5 AWG)
Remote Cable: 1.5mm² (15 AWG)
Dimensions:
239.2mm (L) × 180.5mm (W) × 64.1mm (H)
9.41" × 7.10" × 2.52"
Net Weight: 2.85kg (6.28 lb)
Gross Weight: 3.25kg (7.16 lb)
2 Ohm Version
Currently unavailable
